GW Series Indoor LED Video Wall
GW Series
Fine Pixel Pitch LED Display Technology
Indoor LED video wall solutions from Gravityās GW Series deliver exceptional image clarity, fine pixel pitch options and seamless integration for commercial display environments.
Using RGB 3 in 1 package and SMD technology.
Automatic manufacture archives high quality and high precision optical effect.
Key Features
Modular Formation
Customise the screen size and shape to fit your desired environment.
Easy Maintenance
Direct front access to critical components allows for quick, convenient maintenance.
Seamless Black Surface
Aesthetically complement any luxury space with a sleek, black surface and bezel-less look.
Energy saving & low consumption
High heat dissipation panel, low temperature rise, longer lifespan.
Cabinet with 3:4 aspect ratio design. Supporting point-to-point display.
Internal routing design, clean and beautiful appearance. Efficiemcy heat dissipation panel processing technology, low temperature rising, longer working life.
Module solution
Seamless splicing and the flexibility to customize the screen size to suit your needs. Suitable for a wide range of applications, including hotels, shopping malls, exhibition halls, window displays, large party events, and so on.
The ultimate precision, die-cast aluminum cabinet, perfect seamless. Alignment groove + positioning pin design.
SPECIFICATIONS
| Model | GW-12L | GW-15L | GW-18L | GW-20L | GW-25L | GW-30L | GW-40L |
|---|---|---|---|---|---|---|---|
| Pixel Pitch | P1.25 | P1.5625 | P1.875 | P2.0 | P2.5 | P3.076 | P4.0 |
| LED Type | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Module Resolution | 256Ć128 | 208Ć104 | 172Ć86 | 160Ć80 | 128Ć64 | 104Ć52 | 80Ć40 |
| Cabinet Resolution | 512Ć384 | 416Ć312 | 344Ć258 | 320Ć240 | 256Ć192 | 208Ć156 | 160Ć120 |
| Module Size (mm) | 320 Ć 160 Ć 17 | ||||||
| Cabinet Size (mm) | 640 Ć 480 Ć 61 | ||||||
| Cabinet Weight | 7.2 kg | ||||||
| Viewing Angle | 160Ā° / 160Ā° | ||||||
| Brightness | 600 cd/mĀ² | ||||||
| Contrast Ratio | 4000 : 1 | ||||||
| Color Temperature | 3000 ā 9300K (adjustable) | ||||||
| Refresh Rate | 60 Hz | ||||||
| Frame Frequency | ā¤ 3840 Hz | ||||||
| Power Consumption (Max) | ā¤ 600 W/mĀ² | ||||||
| Power Consumption (Typical) | ā¤ 200 W/mĀ² | ||||||
| Working Voltage | AC 100V ā 240V, 50ā60Hz | ||||||
| Lifetime | 100,000 hours | ||||||
| Operating Temperature | -10Ā°C ~ +50Ā°C | ||||||
| Operating Humidity | 10% ā 80% | ||||||
